Panasonic and domestic GKG fully automatic printing presses new and used models available for rent or sale!
2025-09-16
Becky Su
ZK Electronic
SMT Fully Automatic Printing Presses Panasonic and GKG Printer Rental Sales Available!
Key Models & Specs
Here are several models from GKG and Panasonic, with their features
| Model | Manufacturer | Key Specs & Features |
|---|---|---|
| GKG G5 Fully Automatic SMT Stencil Printer | GKG | • PCB sizes: 50×50 mm up to 1200×800 mm • PCB thickness: ~0.4-14 mm • High-precision stencil system, adaptive scraper; minimal human intervention. |
| GKG GT++ SMT Stencil Printer | GKG | • PCB size up to 510×510 mm • Substrate (PCB) thickness: 0.4-6 mm (some sources say up to 14 mm depending on variant) • Repeat/placement accuracy in the ±12.5-18 µm range at 6σ, CPK≥2.0 • Scraper speed: 6-200 mm/sec; pressure 0.5-10 kg; various cleaning modes (dry, wet, vacuum) |
| GKG G9 | GKG | • Similar range: print size ~530×340 mm; frame size ~370-737 mm; accuracy ±12.5 µm; cycle time < ~7.5 s; uses CCD vision etc. |
| GKG G-Titan Series | GKG (Domestic / “lower cost” line) | • Adjustable frame size ~470×370 mm up to 737×737 mm • Cycle time excluding cleaning/printing ~<8.5 s • Automatic PCB thickness adjust; flexible board clamping & support; designed for lower volume or cost-optimized use. |
| GKG GSE | GKG | • PCB size up to 400×340 mm; frame sizes up to ~737×737 mm • Cycle time ~<8 s (excluding cleaning) • Accuracy ±0.01 mm repeat; printing accurate to ±0.025 mm in test conditions |
| Panasonic NPM-GP/L (Screen / Solder Paste Printer) | Panasonic | • PCB sizes: ~50×50 mm up to ~510×510 mm • Cycle time ~12 seconds (varies by board size etc.) including cleaning and transport for a mid-size board (250×150 mm) • Very high repeat-position accuracy: ±3.8 µm (2 Cpk) for repeated positioning; printing accuracy ±15 µm under spec conditions. |
Availability — New vs Used
New units are available from GKG or their dealers, especially G5, GT++, G9, GSE lines.
Used / OEM refurbished units also show up on platforms like SMTBank. E.g., GKG GT++ is listed “used/new” there.
Panasonic new printers (e.g. NPM-GP/L) are sold via official Panasonic SMT / electronics-assembly channels. Used ones may be harder to source in “like-new” condition.
I didn’t find strong public listings for renting these exact machines, but many SMT equipment distributors and local brokers might offer rental or lease-to-own.
GKG printer,Panasonic machine
